DragonOS Noble: Mapping VDL2 + HFDL Aircraft Traffic in Grafana (RTLSDR v4, Airspy Discovery HF+)
You’ll see how both data sources come together to ...visualize live aircraft positions, frequency stats, and message logs, all mapped and searchable inside Grafana.
🧠 Highlights:
- Overview of dumpvdl2 and the type of aircraft traffic it decodes
- Integration of VDL2 and HFDL pipelines into the Grafana stack
- Mapping and exploring aircraft position data in real time
- How data flows from SDR → dumpvdl2/dumphfdl → Graphite/Loki → Grafana
- Why having all this in Grafana unlocks new ways to explore, filter, and analyze aviation data
🔗 Repositories and Resources
📁
- https://github.com/alphafox02/dumphfdl-grafana-stack
💡 Note: The dev branch includes persistent volume settings for Grafana, Loki, and Graphite — so dashboards and data remain intact after container restarts.
▶️ Previous Video (HFDL Setup)
📺 https://youtu.be/SrcyvaXPUGI
💬 Notes
Once configured, you can explore flight data interactively — from log details to frequency trends — directly on the map and dashboard panels.
WarDragon Pro available here (when in stock): https://cemaxecuter.com/?product=wardragon-pro-kit
Don’t miss out on staying connected: Catch updates on X: https://x.com/cemaxecuter
Supporting the channel: If you find this content helpful, please consider supporting the channel through Patreon: https://www.patreon.com/cemaxecuter
#HFDL #DragonOS #Grafana #Airspy #SDR #HF #Aviation #SignalsIntelligence #SoftwareDefinedRadioShow More
